Beyond Azure Monitor - Part 3: Building Production-Ready Monitoring Solutions
Beyond Azure Monitor - Part 3: Production-Ready Monitoring
Automation, Alerting Strategies, and Integration
PURPOSE
Parts 1 and 2 gave you the patterns. Queries that build confidence in your alerts and confidence that you’re seeing the whole picture. But patterns that run manually are just tools sitting in a drawer. This part makes them operational: automated deployment, intelligent alerting strategies, and integration with the systems your team already uses.
The goal isn’t more dashboards. It’s monitoring that runs without you, escalates appropriately, and fixes what it can fix so your teams aren’t constantly worn out.
Fair Warning: These patterns require Azure automation capabilities, integration planning, and organizational buy-in. The technical implementation is the easy part. Getting your team to have confidence in automated remediation is harder. Start small, build confidence, expand from success.
WALKTHROUGH
Pattern: Infrastructure-as-Code Alert Deployment
Here’s a pattern I’ve seen kill monitoring programs: alerts created manually in the portal, configured differently across environments, undocumented, and impossible to reproduce when something breaks.
I’ve inherited environments where nobody knew why certain alerts existed, what thresholds were set, or who configured them. The person who built the monitoring left two years ago. The documentation, if it ever existed, didn’t survive the last wiki migration. So the team was afraid to touch anything, and the alerts slowly drifted into uselessness.
Infrastructure as Code solves this. Your alerts live in source control. They deploy consistently. They’re documented by their existence. When someone asks “why does this alert fire at 75%?” the answer is in the Bicep template, not in someone’s memory.
// Intelligent alert deployment template
// Purpose: Deploy context-aware alerts with dynamic thresholds
// Usage: Deploy via Azure DevOps or GitHub Actions for consistent alerting
@description('Resource group for monitoring resources')
param resourceGroupName string
@description('Log Analytics workspace resource ID')
param workspaceResourceId string
@description('Action group for alert notifications')
param actionGroupId string
@description('Environment tag for alert customization')
@allowed(['dev', 'staging', 'prod'])
param environment string = 'prod'
// Dynamic thresholds based on environment
var alertThresholds = {
dev: {
cpuThreshold: 90
responseTimeMultiplier: 3
errorRateThreshold: 10
}
staging: {
cpuThreshold: 85
responseTimeMultiplier: 2.5
errorRateThreshold: 5
}
prod: {
cpuThreshold: 75
responseTimeMultiplier: 2
errorRateThreshold: 2
}
}
// Context-aware CPU alert with business hours logic
resource cpuAlert 'Microsoft.Insights/scheduledQueryRules@2023-03-15-preview' = {
name: 'intelligent-cpu-monitoring-${environment}'
location: resourceGroup().location
properties: {
displayName: 'Intelligent CPU Monitoring - ${toUpper(environment)}'
description: 'Context-aware CPU monitoring with business hours and maintenance awareness'
severity: environment == 'prod' ? 2 : 3
enabled: true
evaluationFrequency: 'PT5M'
windowSize: 'PT15M'
criteria: {
allOf: [
{
query: '''
let businessHours = datatable(['Day of Week']:int, ['Start Hour']:int, ['End Hour']:int) [
1, 8, 18, 2, 8, 18, 3, 8, 18, 4, 8, 18, 5, 8, 18
];
Perf
| where TimeGenerated > ago(15m)
| where ObjectName has 'processor'
and CounterName has 'processor time'
and InstanceName has 'total'
| extend ['Day of Week'] = toint(dayofweek(TimeGenerated) / 1d)
| extend ['Current Hour'] = hourofday(TimeGenerated)
| join kind=leftouter businessHours on ['Day of Week']
| extend ['Is Business Hours'] = (['Current Hour'] >= ['Start Hour'] and ['Current Hour'] <= ['End Hour'])
| extend ['CPU Threshold'] = iff(['Is Business Hours'], ${alertThresholds[environment].cpuThreshold - 10}, ${alertThresholds[environment].cpuThreshold})
| where CounterValue > ['CPU Threshold']
| summarize
['Average CPU'] = avg(CounterValue),
['Sample Count'] = count()
by Computer, bin(TimeGenerated, 5m)
| where ['Sample Count'] >= 3
'''
timeAggregation: 'Count'
operator: 'GreaterThan'
threshold: 0
failingPeriods: {
numberOfEvaluationPeriods: 2
minFailingPeriodsToAlert: 1
}
}
]
}
actions: {
actionGroups: [actionGroupId]
customProperties: {
environment: environment
alertType: 'infrastructure'
automationCapable: 'true'
}
}
}
}
// Application performance anomaly alert
resource performanceAnomalyAlert 'Microsoft.Insights/scheduledQueryRules@2023-03-15-preview' = {
name: 'performance-anomaly-detection-${environment}'
location: resourceGroup().location
properties: {
displayName: 'Performance Anomaly Detection - ${toUpper(environment)}'
description: 'Statistical anomaly detection for application response times'
severity: environment == 'prod' ? 1 : 2
enabled: true
evaluationFrequency: 'PT10M'
windowSize: 'PT1H'
criteria: {
allOf: [
{
query: '''
let sensitivityFactor = ${alertThresholds[environment].responseTimeMultiplier};
let historicalPattern = AppRequests
| where TimeGenerated between (ago(14d) .. ago(1h))
| extend ['Hour of Day'] = hourofday(TimeGenerated)
| summarize
['Baseline Mean'] = avg(DurationMs),
['Baseline StdDev'] = stdev(DurationMs)
by Name, ['Hour of Day']
| where ['Baseline Mean'] > 0;
let currentPerformance = AppRequests
| where TimeGenerated > ago(1h)
| extend ['Hour of Day'] = hourofday(TimeGenerated)
| summarize ['Current Mean'] = avg(DurationMs) by Name, ['Hour of Day'];
historicalPattern
| join kind=inner currentPerformance on Name, ['Hour of Day']
| extend ['Anomaly Threshold'] = ['Baseline Mean'] + (sensitivityFactor * ['Baseline StdDev'])
| where ['Current Mean'] > ['Anomaly Threshold']
| extend ['Severity Score'] = (['Current Mean'] - ['Baseline Mean']) / ['Baseline StdDev']
| where ['Severity Score'] > 2.0
'''
timeAggregation: 'Count'
operator: 'GreaterThan'
threshold: 0
}
]
}
actions: {
actionGroups: [actionGroupId]
customProperties: {
environment: environment
alertType: 'application'
automationCapable: 'true'
}
}
}
}What this does:
The template deploys alerts with environment-aware thresholds. Production gets tighter thresholds and higher severity. Dev gets more tolerance. The alerts themselves contain the context-aware KQL from Part 1, so they only fire when conditions actually warrant attention.
The customProperties block is important. Those tags enable downstream automation to know what kind of alert this is and whether it’s safe to auto-remediate. That metadata becomes critical when you start building self-healing capabilities.
Adapt for your environment:
- Add additional alert rules for the patterns from Part 2
- Modify threshold values based on your SLAs
- Add tags for cost tracking and ownership
- Consider separate action groups for different severity levels
Pattern: PowerShell Deployment Automation
Bicep gets you consistent deployment. PowerShell gets you lifecycle management: deploy new alerts, update existing ones, validate changes before committing, report on what changed and why.
I built this pattern after watching a deployment overwrite carefully tuned thresholds because nobody remembered they’d been adjusted post-deployment. The script now checks for existing alerts and reports what it’s about to change before changing it.
# Automated alert deployment and management script
# Purpose: Deploy and manage intelligent alerts across multiple environments
# Usage: Run from Azure DevOps pipeline or scheduled automation
param(
[Parameter(Mandatory=$true)]
[string]$SubscriptionId,
[Parameter(Mandatory=$true)]
[string]$ResourceGroupName,
[Parameter(Mandatory=$true)]
[ValidateSet('dev', 'staging', 'prod')]
[string]$Environment,
[Parameter(Mandatory=$false)]
[switch]$ValidateOnly
)
# Connect to Azure (assumes managed identity or service principal)
Connect-AzAccount -Identity
# Set subscription context
Set-AzContext -SubscriptionId $SubscriptionId
# Define alert configurations
$alertConfigs = @{
'intelligent-cpu-monitoring' = @{
DisplayName = "Intelligent CPU Monitoring - $($Environment.ToUpper())"
Query = @'
let businessHours = datatable(['Day of Week']:int, ['Start Hour']:int, ['End Hour']:int) [
1, 8, 18, 2, 8, 18, 3, 8, 18, 4, 8, 18, 5, 8, 18
];
Perf
| where TimeGenerated > ago(15m)
| where ObjectName has 'processor'
and CounterName has 'processor time'
and InstanceName has 'total'
| extend ['Day of Week'] = toint(dayofweek(TimeGenerated) / 1d)
| extend ['Current Hour'] = hourofday(TimeGenerated)
| join kind=leftouter businessHours on ['Day of Week']
| extend ['Is Business Hours'] = (['Current Hour'] >= ['Start Hour'] and ['Current Hour'] <= ['End Hour'])
| extend ['CPU Threshold'] = iff(['Is Business Hours'], 70.0, 85.0)
| where CounterValue > ['CPU Threshold']
| summarize
['Average CPU'] = avg(CounterValue),
['Sample Count'] = count()
by Computer, bin(TimeGenerated, 5m)
| where ['Sample Count'] >= 3
'@
Severity = if ($Environment -eq 'prod') { 2 } else { 3 }
Frequency = 'PT5M'
WindowSize = 'PT15M'
}
'capacity-prediction' = @{
DisplayName = "Capacity Prediction Alert - $($Environment.ToUpper())"
Query = @'
let forecastDays = 7;
let trendPeriod = 30d;
let capacityThreshold = 85.0;
Perf
| where TimeGenerated > ago(trendPeriod)
| where ObjectName has 'logicaldisk'
and CounterName has '% free space'
and InstanceName !has '_total'
| extend ['Used Percentage'] = 100 - CounterValue
| summarize
['Current Usage'] = avg(['Used Percentage']),
['Usage Trend'] = (max(['Used Percentage']) - min(['Used Percentage'])) / 30
by Computer, InstanceName
| where ['Usage Trend'] > 0
| extend ['Days to Threshold'] = (capacityThreshold - ['Current Usage']) / ['Usage Trend']
| where ['Days to Threshold'] <= forecastDays and ['Days to Threshold'] > 0
'@
Severity = if ($Environment -eq 'prod') { 1 } else { 2 }
Frequency = 'PT1H'
WindowSize = 'PT24H'
}
}
# Function to deploy or validate alerts
function Deploy-IntelligentAlert {
param(
[string]$AlertName,
[hashtable]$Config,
[string]$WorkspaceId,
[string]$ActionGroupId,
[bool]$ValidateOnly
)
$alertParams = @{
Name = "$AlertName-$Environment"
ResourceGroupName = $ResourceGroupName
Location = (Get-AzResourceGroup -Name $ResourceGroupName).Location
DisplayName = $Config.DisplayName
Description = "Automated deployment of $AlertName for $Environment environment"
Severity = $Config.Severity
Enabled = $true
EvaluationFrequency = $Config.Frequency
WindowSize = $Config.WindowSize
Query = $Config.Query
ActionGroupId = $ActionGroupId
}
if ($ValidateOnly) {
Write-Host "Validation: Would deploy alert '$($Config.DisplayName)'" -ForegroundColor Yellow
Write-Host " Query length: $($Config.Query.Length) characters" -ForegroundColor Gray
return $true
}
try {
$existingAlert = Get-AzScheduledQueryRule -ResourceGroupName $ResourceGroupName -Name $alertParams.Name -ErrorAction SilentlyContinue
if ($existingAlert) {
Write-Host "Updating existing alert: $($Config.DisplayName)" -ForegroundColor Blue
Set-AzScheduledQueryRule @alertParams
} else {
Write-Host "Creating new alert: $($Config.DisplayName)" -ForegroundColor Green
New-AzScheduledQueryRule @alertParams
}
return $true
}
catch {
Write-Error "Failed to deploy alert '$($Config.DisplayName)': $($_.Exception.Message)"
return $false
}
}
# Get workspace and action group details
$workspace = Get-AzOperationalInsightsWorkspace -ResourceGroupName $ResourceGroupName
$actionGroup = Get-AzActionGroup -ResourceGroupName $ResourceGroupName | Select-Object -First 1
if (-not $workspace -or -not $actionGroup) {
throw "Required Log Analytics workspace or Action Group not found in resource group '$ResourceGroupName'"
}
# Deploy all configured alerts
$deploymentResults = @()
foreach ($alertName in $alertConfigs.Keys) {
$result = Deploy-IntelligentAlert -AlertName $alertName -Config $alertConfigs[$alertName] -WorkspaceId $workspace.ResourceId -ActionGroupId $actionGroup.Id -ValidateOnly $ValidateOnly.IsPresent
$deploymentResults += @{
AlertName = $alertName
Success = $result
Environment = $Environment
}
}
# Report results
Write-Host "`nDeployment Summary:" -ForegroundColor Cyan
$deploymentResults | ForEach-Object {
$status = if ($_.Success) { "SUCCESS" } else { "FAILED" }
$color = if ($_.Success) { "Green" } else { "Red" }
Write-Host " $($_.AlertName): $status" -ForegroundColor $color
}
$successCount = ($deploymentResults | Where-Object { $_.Success }).Count
$totalCount = $deploymentResults.Count
Write-Host "`nDeployed $successCount of $totalCount alerts successfully for $Environment environment" -ForegroundColor $(if ($successCount -eq $totalCount) { "Green" } else { "Yellow" })What this does:
The script manages alert lifecycle: create new alerts, update existing ones, validate before deployment. The -ValidateOnly switch is the critical feature. Run it in your pipeline before the actual deployment. See what’s about to change. Catch mistakes before they become incidents.
Adapt for your environment:
- Add additional alert configurations from Parts 1 and 2
- Integrate with your CI/CD pipeline
- Add rollback capability for failed deployments
- Consider storing alert configurations in external files for easier management
Pattern: Alert Suppression and Correlation
Alert storms are real. I’ve seen 200 alerts fire in 10 minutes during a single incident, each one yelling like it’s the most important, each one creating noise that makes the actual problem harder to find. By the time you’ve acknowledged all the alerts, the incident is over and you’ve learned nothing except that your monitoring needs work.
This pattern suppresses alerts during maintenance windows, filters out known issues, and correlates related alerts into incident groups. Instead of 200 individual alerts, you get one incident with context.
// Intelligent alert suppression during maintenance and known issues
// Purpose: Prevent alert storms during planned maintenance and correlate related alerts
// Returns: Filtered alerts with suppression logic and correlation grouping
let maintenanceWindows = externaldata(['Server Name']:string, ['Maintenance Start']:datetime, ['Maintenance End']:datetime) [
@'https://yourstorageaccount.blob.core.windows.net/config/maintenance-schedule.csv'
] with (format='csv', ignoreFirstRecord=true);
let knownIssues = externaldata(['Issue ID']:string, ['Affected Services']:string, ['Start Time']:datetime, ['End Time']:datetime) [
@'https://yourstorageaccount.blob.core.windows.net/config/known-issues.csv'
] with (format='csv', ignoreFirstRecord=true);
let alertCorrelation = datatable(['Primary Alert']:string, ['Related Alerts']:dynamic) [
'DatabaseConnectionFailure', dynamic(['HighCPU', 'SlowResponse', 'MemoryPressure']),
'NetworkLatency', dynamic(['SlowResponse', 'TimeoutErrors']),
'DiskSpaceWarning', dynamic(['SlowDiskIO', 'HighCPU'])
];
let rawAlerts = AlertsManagementResources
| where TimeGenerated > ago(1h)
| where properties.essentials.alertState == 'New'
and properties.essentials.severity in ('Sev0', 'Sev1', 'Sev2')
| extend ['Alert Name'] = tostring(properties.essentials.alertRule)
| extend ['Affected Resource'] = tostring(properties.essentials.targetResource)
| extend ['Alert Severity'] = tostring(properties.essentials.severity)
| extend ['Alert Time'] = todatetime(properties.essentials.startDateTime);
rawAlerts
| join kind=leftouter maintenanceWindows on $left.['Affected Resource'] == $right.['Server Name']
| join kind=leftouter knownIssues on $left.['Alert Name'] == $right.['Affected Services']
| where (['Alert Time'] !between (['Maintenance Start'] .. ['Maintenance End'])) // Not during maintenance
and (['Alert Time'] !between (['Start Time'] .. ['End Time'])) // Not during known issues
| join kind=leftouter alertCorrelation on $left.['Alert Name'] == $right.['Primary Alert']
| extend ['Suppression Reason'] = case(
['Alert Time'] between (['Maintenance Start'] .. ['Maintenance End']), 'Planned Maintenance',
['Alert Time'] between (['Start Time'] .. ['End Time']), strcat('Known Issue: ', ['Issue ID']),
'None')
| extend ['Correlation Group'] = iff(isnotnull(['Related Alerts']), ['Alert Name'], 'Standalone')
| where ['Suppression Reason'] == 'None' // Only unsuppressed alerts
| summarize
['Alert Count'] = count(),
['Severity Levels'] = make_set(['Alert Severity']),
['Affected Resources'] = make_set(['Affected Resource']),
['First Alert'] = min(['Alert Time']),
['Latest Alert'] = max(['Alert Time'])
by ['Correlation Group']
| extend ['Incident Priority'] = case(
['Alert Count'] >= 5 and ['Severity Levels'] has 'Sev0', 'Critical',
['Alert Count'] >= 3 and ['Severity Levels'] has 'Sev1', 'High',
['Alert Count'] >= 2, 'Medium',
'Low')
| project
['Incident Group'] = ['Correlation Group'],
['Priority'] = ['Incident Priority'],
['Alert Count'],
['Resource Count'] = array_length(['Affected Resources']),
['Duration Minutes'] = datetime_diff('minute', ['Latest Alert'], ['First Alert']),
['Affected Resources'] = ['Affected Resources']
| order by ['Priority'] desc, ['Alert Count'] descWhat this does:
The query pulls maintenance windows and known issues from external CSV files, suppresses alerts that fall within those windows, and groups related alerts into correlation clusters. The output is incident groups with priority scores rather than individual alerts.
The externaldata approach is intentional. Your maintenance windows should live somewhere your change management process can update them. When someone schedules maintenance in ServiceNow or your ticketing system, that data should flow into these CSV files automatically. The query adapts without code changes.
Adapt for your environment:
- Replace the storage account URLs with your actual configuration sources
- Expand the correlation mappings based on your service dependencies
- Consider pulling maintenance windows from your ITSM system via API
- Add additional suppression rules for deployment windows
Pattern: Business Impact Scoring
Not all alerts are equal. An authentication service at 50% error rate affects everyone. A reporting service with the same error rate affects five people who can wait.
I’ve watched teams treat every Sev1 the same, scrambling on incidents that didn’t actually matter while ignoring degradation in critical paths. The severity level in the alert doesn’t know your business. You have to teach it.
This pattern scores alerts based on business criticality, user count, and revenue implications. The output tells you not just that something is broken, but how urgently it needs attention and who should be notified.
// Business impact scoring for intelligent alert prioritization
// Purpose: Score alerts based on business impact, user count, and revenue implications
// Returns: Prioritized alerts with business context and recommended response times
let businessServices = datatable(['Service Name']:string, ['Business Criticality']:string, ['User Count']:int, ['Revenue Impact']:string) [
'OrderProcessing', 'Critical', 50000, 'High',
'UserAuthentication', 'Critical', 100000, 'High',
'ProductCatalog', 'High', 75000, 'Medium',
'ReportingService', 'Medium', 5000, 'Low',
'AdminPortal', 'Low', 100, 'Low'
];
let serviceHealth = AppRequests
| where TimeGenerated > ago(30m)
| summarize
['Success Rate'] = (count() - countif(Success == false)) * 100.0 / count(),
['Avg Response Time'] = avg(DurationMs),
['Error Count'] = countif(Success == false),
['Total Requests'] = count()
by Name
| join kind=inner businessServices on $left.Name == $right.['Service Name'];
let performanceIssues = serviceHealth
| where ['Success Rate'] < 95.0 or ['Avg Response Time'] > 2000
| extend ['Performance Score'] = case(
['Success Rate'] < 90.0, 10, // Critical performance
['Success Rate'] < 95.0, 7, // Degraded performance
['Avg Response Time'] > 5000, 8, // Very slow
['Avg Response Time'] > 2000, 5, // Slow
0)
| extend ['Business Impact Score'] = case(
['Business Criticality'] == 'Critical', 10,
['Business Criticality'] == 'High', 7,
['Business Criticality'] == 'Medium', 4,
1)
| extend ['User Impact Score'] = case(
['User Count'] > 50000, 10,
['User Count'] > 10000, 7,
['User Count'] > 1000, 4,
1)
| extend ['Revenue Impact Score'] = case(
['Revenue Impact'] == 'High', 10,
['Revenue Impact'] == 'Medium', 6,
['Revenue Impact'] == 'Low', 2,
0)
| extend ['Total Impact Score'] = ['Performance Score'] + ['Business Impact Score'] + ['User Impact Score'] + ['Revenue Impact Score']
| extend ['Response SLA'] = case(
['Total Impact Score'] >= 30, '15 minutes',
['Total Impact Score'] >= 20, '30 minutes',
['Total Impact Score'] >= 15, '1 hour',
['Total Impact Score'] >= 10, '2 hours',
'4 hours')
| extend ['Escalation Level'] = case(
['Total Impact Score'] >= 35, 'Executive',
['Total Impact Score'] >= 25, 'Management',
['Total Impact Score'] >= 15, 'Senior Engineer',
'On-Call Engineer')
| project
['Service'] = Name,
['Current Success Rate'] = round(['Success Rate'], 1),
['Current Response Time'] = round(['Avg Response Time'], 0),
['Affected Users'] = ['User Count'],
['Business Priority'] = ['Business Criticality'],
['Impact Score'] = ['Total Impact Score'],
['Required Response Time'] = ['Response SLA'],
['Escalation Level']
| order by ['Impact Score'] descWhat this does:
The query combines real-time service health with business metadata to calculate composite impact scores. The output tells you not just that something is broken, but how urgently it needs attention and who should be notified.
The ['Escalation Level'] column is where this pays off. When authentication is down, the right people find out immediately. When the admin portal is slow, it routes to the on-call engineer who can address it during normal hours. Same monitoring system, different response based on what actually matters.
Adapt for your environment:
- Pull business service metadata from your CMDB instead of hardcoding
- Adjust scoring weights based on your business priorities
- Add time-of-day awareness (issues during peak hours score higher)
- Integrate with on-call scheduling to route to the right person
Pattern: ServiceNow Integration
Events from alerts that don’t create incidents get forgotten. Incidents that don’t have context take longer to resolve. This pattern bridges Azure Monitor and your ITSM platform with intelligent routing and full alert context.
I’m using ServiceNow here because it has native Azure integration and it’s what most enterprises run. But the pattern applies to any ITSM platform. ServiceNow gives you out-of-the-box connectors. Jira Service Management, Freshservice, or your homegrown system will need custom webhook integration. The logic is identical. The plumbing changes.
I’ve seen the alternative: generic incidents with “Azure Alert Fired” as the description, assigned to a catch-all queue, waiting hours for someone to figure out what actually happened. By the time they do, the alert has auto-resolved and nobody learns anything.
# ServiceNow incident creation with intelligent routing
# Purpose: Automatically create ServiceNow incidents from Azure alerts with proper categorization
# Usage: Called from Azure Logic Apps or Function Apps triggered by alerts
param(
[Parameter(Mandatory=$true)]
[string]$AlertPayload,
[Parameter(Mandatory=$true)]
[string]$ServiceNowInstance,
[Parameter(Mandatory=$true)]
[string]$ServiceNowUser,
[Parameter(Mandatory=$true)]
[string]$ServiceNowPassword
)
# Parse alert payload
$alert = $AlertPayload | ConvertFrom-Json
# Business impact mapping
$impactMapping = @{
'Critical' = @{ Impact = '1'; Urgency = '1'; Priority = '1' }
'High' = @{ Impact = '2'; Urgency = '2'; Priority = '2' }
'Medium' = @{ Impact = '3'; Urgency = '3'; Priority = '3' }
'Low' = @{ Impact = '4'; Urgency = '4'; Priority = '4' }
}
# Service mapping for assignment groups
$serviceMapping = @{
'OrderProcessing' = 'E-Commerce Platform Team'
'UserAuthentication' = 'Identity Services Team'
'ProductCatalog' = 'Content Management Team'
'ReportingService' = 'Business Intelligence Team'
'AdminPortal' = 'Internal Tools Team'
}
# Extract service name from alert
$serviceName = ($alert.data.essentials.alertTargetIDs | ForEach-Object {
($_ -split '/')[-1]
}) | Select-Object -First 1
# Determine business impact
$businessImpact = 'Medium' # Default
if ($alert.data.essentials.severity -eq 'Sev0') { $businessImpact = 'Critical' }
elseif ($alert.data.essentials.severity -eq 'Sev1') { $businessImpact = 'High' }
elseif ($alert.data.essentials.severity -eq 'Sev2') { $businessImpact = 'Medium' }
else { $businessImpact = 'Low' }
# Build ServiceNow incident
$incidentData = @{
short_description = "Azure Alert: $($alert.data.essentials.alertRule)"
description = @"
Alert Details:
- Alert Rule: $($alert.data.essentials.alertRule)
- Severity: $($alert.data.essentials.severity)
- Resource: $serviceName
- Start Time: $($alert.data.essentials.startDateTime)
- Description: $($alert.data.essentials.description)
Business Impact: $businessImpact
Affected Service: $serviceName
Alert Context:
$($alert.data.alertContext | ConvertTo-Json -Depth 3)
"@
impact = $impactMapping[$businessImpact].Impact
urgency = $impactMapping[$businessImpact].Urgency
priority = $impactMapping[$businessImpact].Priority
category = 'Infrastructure'
subcategory = 'Monitoring Alert'
assignment_group = $serviceMapping[$serviceName] ?? 'Platform Operations'
caller_id = $ServiceNowUser
contact_type = 'Monitoring System'
state = '2' # In Progress
u_alert_source = 'Azure Monitor'
u_alert_id = $alert.data.essentials.alertId
u_correlation_id = $alert.data.essentials.alertId
}
# ServiceNow API call
$base64Auth = [Convert]::ToBase64String([Text.Encoding]::ASCII.GetBytes("${ServiceNowUser}:${ServiceNowPassword}"))
$headers = @{
'Authorization' = "Basic $base64Auth"
'Content-Type' = 'application/json'
'Accept' = 'application/json'
}
$uri = "https://$ServiceNowInstance.service-now.com/api/now/table/incident"
try {
$response = Invoke-RestMethod -Uri $uri -Method Post -Headers $headers -Body ($incidentData | ConvertTo-Json -Depth 3)
Write-Host "ServiceNow incident created successfully:" -ForegroundColor Green
Write-Host " Incident Number: $($response.result.number)" -ForegroundColor White
Write-Host " Incident SysID: $($response.result.sys_id)" -ForegroundColor White
Write-Host " Priority: $($response.result.priority)" -ForegroundColor White
Write-Host " Assignment Group: $($response.result.assignment_group.display_value)" -ForegroundColor White
return @{
Success = $true
IncidentNumber = $response.result.number
IncidentSysId = $response.result.sys_id
Priority = $response.result.priority
}
}
catch {
Write-Error "Failed to create ServiceNow incident: $($_.Exception.Message)"
return @{
Success = $false
Error = $_.Exception.Message
}
}What this does:
The script translates Azure alert severity into ServiceNow impact/urgency/priority, maps affected services to assignment groups, and creates incidents with full context. The correlation ID links the ServiceNow incident back to the Azure alert for tracking.
The u_alert_id and u_correlation_id custom fields are critical for closing the loop. When the alert resolves in Azure, you can automatically update or close the ServiceNow incident. When someone resolves the incident in ServiceNow, you have a direct link to what triggered it.
Adapt for your environment:
- Replace the service-to-team mappings with your actual organizational structure
- Add custom fields specific to your ServiceNow instance
- Consider adding duplicate detection to prevent incident storms
- Integrate with your authentication system (OAuth, managed identity) instead of basic auth
Pattern: Self-Resolving Automation
This is where monitoring becomes operations.
The patterns so far detect problems and route them to humans. This pattern asks: can we fix it automatically? And critically: should we?
I approach self-resolving automation with extreme caution. Automation that makes things worse is worse than no automation. The pattern below includes safety checks, frequency limits, and business hour awareness specifically because I’ve seen automation loops take down production systems. The goal isn’t to automate everything. It’s to automate the safe, repetitive fixes that consume human attention without requiring human judgment.
// Self-healing trigger detection
// Purpose: Identify scenarios where automated remediation can be safely applied
// Returns: Actionable incidents with recommended automation and safety checks
let automationCandidates = datatable(['Issue Pattern']:string, ['Automation Action']:string, ['Safety Requirements']:string, ['Max Frequency']:string) [
'HighMemoryUsage', 'RestartService', 'BusinessHours,LowTraffic', '1per4hours',
'DiskSpaceLow', 'CleanTempFiles', 'Always', '1per1hour',
'ServiceUnresponsive', 'RestartService', 'BusinessHours,HealthCheck', '1per2hours',
'DatabaseConnectionPool', 'RecycleConnections', 'Always', '1per30minutes'
];
let recentIncidents = AlertsManagementResources
| where TimeGenerated > ago(2h)
| where properties.essentials.alertState == 'New'
| extend ['Issue Type'] = case(
properties.essentials.alertRule has 'memory', 'HighMemoryUsage',
properties.essentials.alertRule has 'disk', 'DiskSpaceLow',
properties.essentials.alertRule has 'unresponsive', 'ServiceUnresponsive',
properties.essentials.alertRule has 'connection', 'DatabaseConnectionPool',
'Unknown')
| extend ['Resource Name'] = tostring(split(properties.essentials.targetResource, '/')[-1])
| extend ['Alert Time'] = todatetime(properties.essentials.startDateTime);
let automationHistory = AlertsManagementResources
| where TimeGenerated > ago(24h)
| where properties.customProperties.automationExecuted == 'true'
| extend ['Resource Name'] = tostring(split(properties.essentials.targetResource, '/')[-1])
| extend ['Automation Time'] = todatetime(properties.customProperties.automationTimestamp)
| extend ['Automation Action'] = tostring(properties.customProperties.automationAction);
recentIncidents
| where ['Issue Type'] != 'Unknown'
| join kind=inner automationCandidates on $left.['Issue Type'] == $right.['Issue Pattern']
| join kind=leftouter automationHistory on ['Resource Name'], $left.['Automation Action'] == $right.['Automation Action']
| extend ['Hours Since Last Automation'] = datetime_diff('hour', now(), ['Automation Time'])
| extend ['Frequency Limit Hours'] = case(
['Max Frequency'] == '1per30minutes', 0.5,
['Max Frequency'] == '1per1hour', 1.0,
['Max Frequency'] == '1per2hours', 2.0,
['Max Frequency'] == '1per4hours', 4.0,
24.0)
| extend ['Current Hour'] = hourofday(now())
| extend ['Is Business Hours'] = (['Current Hour'] >= 8 and ['Current Hour'] <= 18)
| extend ['Safety Check Passed'] = case(
['Safety Requirements'] == 'Always', true,
['Safety Requirements'] has 'BusinessHours' and not(['Is Business Hours']), true,
['Safety Requirements'] has 'BusinessHours' and ['Is Business Hours'], false,
true)
| extend ['Frequency Check Passed'] = (isnull(['Hours Since Last Automation']) or ['Hours Since Last Automation'] >= ['Frequency Limit Hours'])
| extend ['Automation Eligible'] = (['Safety Check Passed'] and ['Frequency Check Passed'])
| where ['Automation Eligible']
| project
['Resource'] = ['Resource Name'],
['Issue'] = ['Issue Type'],
['Recommended Action'] = ['Automation Action'],
['Safety Status'] = iff(['Safety Check Passed'], 'Passed', 'Failed'),
['Frequency Status'] = iff(['Frequency Check Passed'], 'Allowed', 'Rate Limited'),
['Last Automation'] = iff(isnull(['Automation Time']), 'Never', format_datetime(['Automation Time'], 'yyyy-MM-dd HH:mm')),
['Alert Time'] = format_datetime(['Alert Time'], 'yyyy-MM-dd HH:mm')
| order by ['Alert Time'] descWhat this does:
The query matches incidents to automation candidates, checks safety requirements (business hours, traffic levels), and enforces frequency limits to prevent automation loops. Only incidents that pass all checks appear in the output.
The frequency limits are non-negotiable. If a service restart didn’t fix the problem, restarting it again in 30 minutes won’t either. But without the limit, automation will keep trying, potentially making things worse. The automationHistory join ensures you know what’s already been attempted.
Adapt for your environment:
- Expand automation candidates based on your runbook library
- Adjust frequency limits based on your risk tolerance
- Add health check verification before allowing service restarts
- Log automation decisions for audit and improvement
CONCLUSION
Queries that run manually are useful. Queries that deploy automatically, suppress noise during maintenance, score business impact, and trigger remediation are operational infrastructure.
These are my examples. They’re the patterns that made sense in the environments I’ve managed, solving the problems I kept running into. They’re not meant to be copied verbatim. They’re frameworks for building monitoring that earns confidence and runs without constant human attention.
Start with one pattern that addresses your biggest pain point. Deploy it. Validate it. Expand from success.
The series is complete. Parts 1 and 2 gave you the intelligence. Part 3 gave you the automation. What you build with them is up to you.
Photo by Carlos Muza on Unsplash
